As UAVs play a greater role in military operations, the pressure to reduce volume and weight is also increasing. Aerospace UAV Connectors are an important basic component that is almost ubiquitous in military and aerospace aircraft & UAV applications and serve as interconnects for transmission signals and power, which has to meet stringent testing for outgassing and residual magnetism to be suitable for use in airspace & UAV applications. Outgassing and residual magnetism can adversely affect nearby components.

Weight & space-saving is necessary for aircraft & UAV connectors because there is only so much room on a space vehicle. They have to be extremely reliable as well and they must resistant to severe environmental conditions like shock, radiation, extreme temperatures, and vibration. In the case of high vibration, shock and temperature cycling, the board to board or box to box connectors of UAV and its cables must also be highly reliable.

Dual High Pressure 138Mpa (20,000PSI) benefit with Glass Sintered Sealing (The air leakage rate: 1×10-3Pa.CM³ /s) technical, support environment temperature -60°C-200°C (harshness especial reach to 260°C max) against API-67 standard requested.

Perforation Gun, A device used to perforate oil and gas wells in preparation for production. Containing several shaped explosive charges, perforating guns are available in a range of sizes and configurations. The diameter of the gun used is typically determined by the presence of wellbore restrictions or limitations imposed by the surface equipment.

Perforation is an extremely important technique in petroleum exploration and recovery engineering, a major means of enhancing the recovery factor of gas and oil wells and also a typical method of tapping the potential of existing oil fields and increasing output.

Perforation completion is widely used worldwide and accounts for about over 90% of all well completions. Almost all reservoir beds can be opened by this method. In the method, in the course of gas and oil field exploitation the production casing is lowered and cemented and then special perforation instrument and devices are sent down to the predetermined depth and aimed at the target layer.

Through the key parts, the firing head connector

The perforator down in the well is ignited from the ground and the lined cavity charge (The propellant material is potassium perchlorate, an oxidizer that burns rapidly, creating CO2. As the shaped charges detonate, the propellant is ignited by extreme heat from the gun system. As it burns, the propellant generates CO2 at high peak pressures typically well above the formation fracture gradient.) is ignited which result in the detonation wave to transmit forward at a velocity of 7~8 km per second and high temperature and high-pressure shock waves are generated which penetrate through the casing, cement sheath and enter the stratum forming a hole canal, as illustrated by the diagram. Whichever perforation method you use, the performance and quality of the perforating gun (Including the perforating gun pipe) shall have a significant influence on the perforation quality of gas and oil wells.

PRESSURE FIRING HEAD CONNECTOR SPECIFICATIONS
Firing Head Connector Part Number	SK19.SYD.001	SK19.SYD.002
O.D. [mm]	28±0.01	28±0.05
Pin connector Length mm	65+0.1	41±0.05
Max. 100 Hour Temperature Rating[oC]†	200	200
Min. Required Pinning Pressure (psi)[MPa]	1,800psi/12MPa	1,800psi/12MPa
Max. Operating Pressure (psi)[MPa]‡	20,000psi/138MPa	20,000psi/138MPa
Air Leakage Rate	1×10-3 Pa.CM3 /s	1×10-3 Pa.CM3 /s
Shell Material	X-750	X-750
Contact Material	Alloy 52 Gold Plating	Alloy 52 Gold Plating
Rated Current per Pin	5A	5A
Dielectric Strength	≥5000MΩ	≥5000MΩ
Contact Resistance	≤10mΩ	≤10mΩ
Life Time	1000times	1000times

Benefits / Capabilities of Sunkye Firing Head Connector

Can re-perforate in old well without pulling the tubing out.

Can be used with big charges to achieve deeper penetration.

Firing circuitry is in short before the charges are released.

Dual Pressure random mounting side

Circulation flexibility—allowed in both directions before and after the guns are fired. Underbalanced perforating conditions are easily established.

CT compatibility—the firing head can take a combination of shear pins and can be connected to any CT string by means of a crossover connector.

Soldering mounting terminal Design efficient assembly to the equipment

Ultra-tiny design fit for the drill head solution and equipment

LAB TEST DATA

Assembly & Mounting Steps

Step 1: Annulus pressure from above the packer enters the crossover tool and is applied to the first (bottom) time delay firing head. The first Sunkye firing sub prevents pressure from reaching the second firing head. The time delay provides time to bleed off pressure. When the guns detonate, the firing train continues to the firing sub. The sub fires, creating a path to the second firing head. The zone is tested.

Step 2: Annulus pressure is reapplied and travels to the second time-delay firing head. The first pressure isolation sub prevents pressure from venting through the first set of perforations. The pressure is released, the gun fires and the second Select Fire sub fires and opens a path to the third gun. Production from the second zone is commingled with pressure from the first zone for testing.

Step 3: Pressure applied to the annulus passes through the annulus pressure crossover and down the control line to the third time-delay firing head. The second pressure isolation sub prevents pressure from venting through perforations in the first and second zones. The pressure is released, the guns fired, and flow from all three are commingled for testing.

If medical equipment fails, it may quickly threaten the health of the patient that means it requires the products and components should meet the most stringent regulations. Sunkye’s mil spec connectors reliably perform their work on a large number of medical devices every day.

The advantages of Sunkye Connectors in the Medical Industry:

Twist pin contact technology, min DIA 2.5mm, super miniature size is available.

Rugged and reliable, High-precision plug-in connections ensure high signal integrity, thus ensuring high performance of instruments and equipment.

Providing high fail-safe protection. It is possible to reliably avoid fluctuations.

Turn-key Solutions for specific requirements.

MEDICAL GRADE CONNECTORS

Application Of Medical Electrical Connectors

Sunkye medical family connector in medical devices encompass variety styles, including those that make the electrical and signal connection through the medical device and equipment system. Sunkye medical Connectors are used to transfer power, signal, data or media and can be designed for just one of these operations or as hybrid systems. No matter what type, they must all be safe and hygienic. Right now matching for the Cardiac pacemaker device, Blood Test Equipment, CT scanner Equipment, Brain MRI Equipment etc.

Sunkye International was one of the medical connector manufacturers to license this technology and improve it. Sunkye focuses on a fully automatic assembly connector’s technology and developing, until nowadays a totally of 14 lines are under manufacturing. Output capacity is 56.92secs/EA,369,000EA/Month.

There are many kinds of connectors, including 2pin and 4Pin types, or other numbers of pins. Some of them can be used as waterproof products, and some of them adopt different electroplating, different directions, welding technology, fasteners and assembly aids. Therefore, connector series products have numerous variants.

Nowadays many connector models are standard configuration, which means there is no mold cost. However, the disadvantage is that the delivery time of connector models may be relatively long. Sometimes, standard solutions may not match your needs. Unique applications and equipment require special electrical connectors. However, custom connector manufacturers and consumers now have many types of connector options. If you can’t find a product that meets your needs, you can use customized connectors. Customized connectors are specially designed and manufactured to meet the specific specifications you need. You can adjust the characteristics, performance, model, etc. of the equipment. It can not only make minor changes to existing products, but also create new products.

CUSTOM CONNECTORS

Application Of Custom Connectors

Customized Ultra-light small size the most harshness environment temperature application in Standard & Non-Standard Parts & Terminal Interconnect Solution.

Sunkye International was one of the electrical connector manufacturers to license this technology and improve it. Sunkye focuses on a fully automatic assembly connector’s technology and developing, until nowadays a totally of 14 lines are under manufacturing. Output capacity is 56.92secs/EA,369,000EA/Month.

Sunkye automotive series connectors onboard power applications in the rail market allow for multiple customer-defined configurations, enable easy assembly and further enhance flexibility with the ability to integrate local cabling and components.

As one of the professional automotive connector manufacturers, Sunkye provides high-quality mil spec connectors automotive and custom connectors for automotive, on and off-highway, and hybrid and electric vehicles to electrically and mechanically join wires and cables, printed circuit boards, integrated circuit packages, and batteries. Automotive power connectors are built to withstand tough conditions and suit the needs of varying applications.

AUTOMOTIVE

Sunkye automobile connectors support high sports performance high-temperature 280℃ connector, Anti-Water & Oil the advantage of heat exhaustion resistance improve the matching performance of the whole automatic. Sports High-Performance Automobile requiring for high-temperature heat exhaustion resistance & high-performance sporting. Sunkye family D108 removable connector Series will reach the high performance which you are thinking.

Connectors are almost everywhere in military and aerospace applications. As the interconnection of transmission signal and power, aircraft d sub connectors must meet the requirements of strict outgassing and residual magnetism test to be suitable for aerospace applications.

Ground to satellite communication is a massively challenging undertaking. People need data fast, with high signal integrity, to quickly assess the message and make decisions. A poor or delayed signal may lead to a wrong conclusion or missed opportunity.

Standards of MIL-C-5015, MIL-C-26482, MIL-DTL-38999, MIL-DTL-55302, MIL-DTL-83513, MIL-DTL-32139.

AEROSPACE ELECTRICAL CONNECTORS

Application Of Aerospace Electrical Connectors

Connectors are an important basic component that is almost ubiquitous in military and aerospace aircraft & aerospace applications and serves as interconnects for transmission signals and power, which has to meet stringent testing for outgassing and residual magnetism to be suitable for use in airspace & aerospace applications , meanwhile, match for system requiresment of anti-irradiation, high-performance vacuum outgassing, adapt to ultra-high temperature and ultra-low temperature extreme environment, non-magnetic, prevent harmful gas intrusion, anti-condensation, vacuum cold welding technology.
