The NEW medium-short range conventional missile, early warning is difficult, intercept even more difficult. It’s a challenge of the connection performance of military-grade weapon systems.
Traditionally, the DF17, a “medium-short range conventional missile” with a range of more than 1,000 kilometers, has been listed as a strategic weapon.
It seems strange.
But actually — this is not nonsense.
In the 21st century, the distinction between traditional strategic and tactical weapons is blurring.
On the one hand, the b-52 and b-2 strategic bombers of the United States were heavily used for tactical missions and even considered has used trident D5 or minuteman 3 missiles to carry conventional warheads for tactical strike missions.
On the other hand, China is now heavily armed with precision strike medium – and long-range missiles with military grade connector that are increasingly strategic.
Because these missiles can destroy thousands of vital targets simultaneously in minutes — in other words, Could disable the U.S. military base in a matter of minutes, Such a strike would be as effective as a nuclear weapon. So these conventional missiles have strategic deterrence.
Currently, DF-26, DF-16, DF-15b, M-20 missiles, and the eagle-20 anti-ship missile under development are both “water drift missiles”, Russia “Iskander”, “Dagger”, and the first generation of hypersonic missiles developed by the U.S. army, navy and air force based on the army’s AHW, all belong to the category of “water drift bomb”.
“Drift bombs” are characterized by re-entry into the atmosphere (as “Iskander” is from the upper thin atmosphere into the relatively dense atmosphere),
The lift generated by the projectile body lifts the missile until it re-exudes the atmosphere, the warhead then re-enters the atmosphere and, after one or more hops, balances lift and gravity for a short period.
Sunkye Military Missile Connector & Umbilical Connector
The phenomenon of a missile gliding at high speed with a very low rate of descent at a given altitude in the atmosphere. However, the glide section of the “water drift” missile is much shorter than that of the lifting body.
To achieve the “medium-short range conventional missile” weapon system, the connection system of Umbilical connector, Standard Military connector and Space connector, etc. Sunkye Military connector rectangle series including Micro D connectors & Nano D connector in the different mounting of crimping/soldering/PCB to PCB/SMT to meet with various system solution applications and terminal device.
| Sunkye Microminiature Connector Product Selection Guide | ||||||||
| R04 | R04J | R04JC | R04JD | R04JS | R04JS1 | R04JA | R04JC | |
| Applications | R04 Connectors are highly reliable, extremely small and higher density contacts configurations than traditional rectangular connectors. | R04J Metal Shell High Density Connectors are designed for use with high performance terminal application. | R04JC Sn-P bronze High reliable connectors | R04JD assembly hole is threaded hole: M2-6H connectors | R04JS Glue sealing connectors | R04JS Glass-Sinter sealing connectors are high performance in the harshest environment. | R04JA | R04JC |
| Available layouts | Plug and Socket | Plug and Socket | Plug and Socket | Plug and Socket | Plug and Socket | Socket | Plug and Socket | Plug and Socket |
| Current Rating | 3A max. | 3A max. | 3A max. | 3A max. | 3A max. | 3A max. | 3A max. | 3A max. |
| Contact | Twist Pin | Twist Pin | Twist Pin | Twist Pin | Twist Pin | Twist Pin | Twist Pin | Twist Pin |
| Contact Resistance | 10 milliohms max. | 10 milliohms max. | 10 milliohms max. | 10 milliohms max. | 10 milliohms max. | 10 milliohms max. | 10 milliohms max. | 10 milliohms max. |
| Shell Material | Plastic PPS | Metal | Metal | Metal | Metal | Metal | Metal | Metal |
| Available layouts of contacts | 9,15,21,25,31,37 & 51 | 9,15,21,25,31,37,51,66,74 &100 | 9,15,21,25,31,37,51,66,74 &100 | 9,15,21,25,31,37,51,66,74 &100 | 9,15,21,25,31,37 & 51 | 9,15,21,25,31,37 & 51 | 9,15,21,25,31,37,51,66,74 &100 | 9,15,21,25,31,37,51,66,74 &100 |
| Terminal Mounting | Crimping | Crimping | Crimping | Crimping | Solder Cup | Solder Cup | Crimping | Crimping |
| Solder Cup | Solder Cup | Solder Cup | Solder Cup | Solder Cup | Solder Cup | |||
| PCB | PCB | PCB | PCB | PCB | PCB | |||
| Right angel 90°to PCB | Right angel 90°to PCB | Right angel 90°to PCB | Right angel 90°to PCB | Right angel 90°to PCB | Right angel 90°to PCB | |||
| RoHS | Availble | Availble | Availble | Availble | Availble | Availble | Availble | Availble |
| Plating | ||||||||
| Factory Terminated | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Space Application | Yes | Yes | Yes | Yes | Yes | No | Yes | Yes |
| Sunkye Nanominiature Connector Product Selection Guide | |||||||
| R06 | R06F | R06M2 | R06M3 | R06M8 | R06C | R06S | |
| Applications | R06 Connectors are used for all kinds of electric circuit system interconnection which have high density, micro,light, highly reliable requirement. It can meet light and miniaturize demand. | R06F Nano right angle PCB Connector series with characters of high density, micro, light, highly reliable. This series have 3 kinds of tail length,which adapts to the diversified needs of products shape | R06M2 Twist flexible micro pin (twist pin), 0.635mm pitch, micro miniature outline dimension | R06M3 Screw nut locking, it is gently when inserted and extract, stably locked | R06M8 is free mounted, not fixed, usually mated with receptacle which have nut. Recommended JC types of screws, tight by miniature stright screwdriver. | R06C crimp termination High reliable connectors | R06S stright to PCB which have 3 kinds of tail length, customized produce for another length |
| Available layouts | Plug and Socket | Plug and Socket | Plug and Socket | Plug and Socket | Plug and Socket | Plug and Socket | Plug and Socket |
| Current Rating | 3A max. | 3A max. | 3A max. | 3A max. | 3A max. | 3A max. | 3A max. |
| Contact | Twist Pin | Twist Pin | Twist Pin | Twist Pin | Twist Pin | Twist Pin | Twist Pin |
| Contact Resistance | 10 milliohms max. | 10 milliohms max. | 10 milliohms max. | 10 milliohms max. | 10 milliohms max. | 10 milliohms max. | 10 milliohms max. |
| Shell Material | Metal | Metal | Metal | Metal | Metal | Metal | Metal |
| Available layouts of contacts | 9,15,21,25,31,37,51,65&69 | 9,15,21,25,31,37,51,65&69 | 9,15,21,25,31,37,51,65&69 | 9,15,21,25,31,37,51,65&69 | 9,15,21,25,31,37,51,65&69 | 9,15,21,25,31,37,51,65&69 | 9,15,21,25,31,37,51,65&69 |
| Terminal Mounting | Crimping Solder Cup PCB Right angel 91°to PCB | Right Angle to PCB | Vertical SMT | Horizontal SMT | Straddle Flexible SMT | Crimping Solder Cup PCB Right angel 90°to PCB | Stright to PCB |
| RoHS Plating | Availble | Availble | Availble | Availble | Availble | Availble | Availble |
| Factory Terminated | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Space Application | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
Sunkye is a professional connector manufacturing company. We provide Micro Crimp Connectors, PCB Connectors, speedy connector, mil spec connectors and so on. Want to know more? Please contact us.
