Aerospace Electrical Connectors

Connectors are almost everywhere in military and aerospace applications. As the interconnection of transmission signal and power, aerospace D sub space grade connectors must meet the requirements of strict outgassing and residual magnetism test to be suitable for aerospace applications.

Ground to satellite communication is a massively challenging undertaking. People need data fast, with high signal integrity, to quickly assess the message and make decisions. A poor or delayed signal may lead to a wrong conclusion or missed opportunity.

Standards of MIL-C-5015, MIL-C-26482, MIL-DTL-38999, MIL-DTL-55302, MIL-DTL-83513, MIL-DTL-32139.

Application Of Aerospace Electrical Connectors

Connectors are an important basic component that is almost ubiquitous in military and aerospace aircraft & aerospace applications and serves as interconnects for transmission signals and power, which has to meet stringent testing for outgassing and residual magnetism to be suitable for use in airspace & aerospace applications , meanwhile, match for system requiresment of anti-irradiation, high-performance vacuum outgassing, adapt to ultra-high temperature and ultra-low temperature extreme environment, non-magnetic, prevent harmful gas intrusion, anti-condensation, vacuum cold welding technology.

Three Basic Types Of Aircraft D Sub Connectors  Classified From A Technical Point Of View

① According to the connection mode: there are threaded connection, bayonet (quick) connection, bayonet lock connection, push-pull connection and direct plug connection;

② According to the shape: circular and rectangular (cross section);

③ According to the working frequency: low frequency and high frequency (with 3MHz as the boundary);

Three Types Of Technical Parameters Of Aerospace Electrical Connectors

① Electrical performance: rated voltage, rated current, contact resistance, withstand voltage and insulation resistance, shielding, RF anti-interference attenuation value;

② Mechanical properties: number of contact pairs and pinhole, installation mode and shape, shell material, insulator, contact, mechanical life, etc.

③ Environmental technical performance: working temperature, working height, vibration, impact, constant acceleration, leakproofness, salt fog, moisture and mould resistance, etc.

Among all the aerospace connector manufacturers, Sunkye can be the one you are looking for.

Sunkye is a professional medical connector supplier, we provide space grade connectors, aerospace d sub connectors, micro dsub connectors, micro 38999 connectors, d sub connector and etc. Want to know aerospace connectors market? Please contact us.
